| Camera Information |
|---|
| CMOS Sensor | onsemi AR0830
|
|---|
| Active Pixels | 3840 (H) x 2160 (V) = 8MP
|
|---|
| Pixel Size | 1.4 μm x 1.4 μm
|
|---|
| Illuminated type | Front Side Illuminated (FSI)
|
|---|
| Maximum S/N Ratio | 39.9 dB
|
|---|
| Input Clock Range | 48 MHz
|
|---|
| Optical Format | 1/2.9” (Diagonal 6.17 mm)
|
|---|
| Shutter Type | Rolling Shutter
|
|---|
| Chromaticity | Color / Mono
|
|---|
| Maximum Frame Rate (YUY2) | 3840 x 2160 @ 15 fps
2560 x 1440 @ 30 fps
1920 x 1080 @ 60 fps
1280 x 720 @ 60 fps
640 x 480 @ 60 fps
|
|---|
| Output Format | YUV422-UYVY
YUV420
RGB888
RGB565
RGB555
JPEG
MJPEG(JPG)
RAW8
RAW10
RAW12
|
|---|
|
| Interface |
|---|
| Module Data Transmission | MIPI CSI-2, up to 4 lanes
|
|---|
| Communication Interface | I2C
|
|---|
| Connector | 70 Pin Standardized Connector
|
|---|
|
| Power Specifications |
|---|
| Supply Voltage | Digital: 3.3V
Analog: 2.8V
I/O: 1.8V
|
|---|
| Power Consumption | TBD
|
|---|
| SW Standby Power | TBD
|
|---|
| HW Standby Power | TBD
|
|---|
|
| Software Support |
|---|
| Platform Support | NVIDIA Jetson AGX Orin
NVIDIA Jetson Orin Nano / NX
NVIDIA Jetson Xavier NX
NVIDIA Jetson Nano
NXP i.MX93 / i.MX95
NXP i.MX8M Nano / Mini / Plus
TI Sitara™ AM62 / AM62A / AM67
TI Sitara™ AM68 / AM69
TI Jacinto™ TDA4VM / TDA4VH
BeagleY®-AI / BeaglePlay®
Raspberry Pi 4 / Raspberry Pi 5
ST STM32MP25
Renesas RZ/V2H
Intel Alder Lake-N
Intel Meteor Lake
|
|---|
| Operation Systems | Linux
Yocto
Android
|
|---|
| SDK | VizionViewer™ / VizionSDK
|
|---|
|
| Environmental and Mechanical |
|---|
| Dimensions | 24.5(W) x 24.5(H) x 3.8(D) mm
|
|---|
| Weight | ≤ 3 grams
|
|---|
| Operation Temperature | -30°C to +70℃
|
|---|
|
| Certification and Compliance |
|---|
| Certification | Compliant with CE / FCC / RoHS / REACH directives
|
|---|
|
| Commercial Information |
|---|
| Brand | TechNexion
|
|---|
| Country of Origin | Taiwan
|
|---|
| HTSN | 8525.89.5050
|
|---|
| ECCN | EAR99
|
|---|
| REACH / RoHS | Yes
|
|---|
|
