| Core System |
|---|
| Processor | NXP i.MX8M Plus
|
|---|
| Architecture | ARM Cortex-A53 + M7
|
|---|
| PMIC | NXP PCA9450
|
|---|
| Memory | Upto 8GB LPDDR4
|
|---|
| Storage | 32GB eMMC (default)
|
|---|
| Board-to-Board Connector | AXON 80-pin Hirose connectors
|
|---|
| System on Module | AXON SOM
|
|---|
| Debug Interface | JTAG / UART
|
|---|
|
| AI / Vision Capabilities |
|---|
| Camera | 2 x ISP up to 12 MP resolution
Dual MIPI CSI (4 lanes)
|
|---|
|
| Connectivity |
|---|
| Network LAN | 1x Realtek RTL8211F
|
|---|
| Wi-Fi | Qualcomm Atheros QCA9377 Wi-Fi 5 – 802.11 a/b/g/n/ac
|
|---|
| Bluetooth | Qualcomm Atheros QCA9377 Bluetooth
|
|---|
| Antenna | MHF4 connector
|
|---|
|
| Signaling |
|---|
| I/O | RGMII
HDMI
LVDS
LAN
MIPI CSI
MIPI DSI
PCIe
USB
USB OTG
I²S
SDIO
CAN
UART
SPI
I²C
PWM
GPIO
|
|---|
|
| Video |
|---|
| GPU Engine | GC520L (2D)
Vivante GC7000UL
|
|---|
| Video decode | 1080p60 (h.265, h.264, VP9, VP8)
|
|---|
| Video encode | 1080p60 (h.265, h.264)
|
|---|
|
| Audio |
|---|
| Audio Codec | Texas Instruments TLV320AIC3100
|
|---|
| Audio Connectors | CTIA compliant 3.5mm audio jack
|
|---|
|
| Power Specifications |
|---|
| Power Consumption | Depending on Configuration
|
|---|
| Power Connector | 2-pin Micro-Fit 3.0
|
|---|
|
| Software Support |
|---|
| Operation Systems | Linux
Yocto
|
|---|
|
| Environmental and Mechanical |
|---|
| Dimensions | 170 (W) x 170 (H) x 26.5 (D) mm
|
|---|
| Weight | 204 grams
|
|---|
| Relative Humidity | 10 to 90 %
|
|---|
| MTBF | 50,000 Hours
|
|---|
| Shock | 15G half-sine 11 ms duration
|
|---|
| Operation Temperature | Commercial: 0°C to +60°C
|
|---|
| Vibration | 1 Grms random 5-500Hz hr/axis
|
|---|
|
| Certification and Compliance |
|---|
| FCC | FCC ID: 2AKZA-QCA9377
|
|---|
| IC | IC: 22364-QCA9377
|
|---|
| CE | EN 300 328 v2.2.2
EN 301 893 v2.1.1
EN 55032 / EN 55024
|
|---|
| TELEC (Japan) | TELEC: 201-180629
|
|---|
| RCM (Australia/New Zealand) | RCM Compliant
|
|---|
| Certification | Compliant with CE / FCC / RoHS / REACH directives
|
|---|
| Bluetooth Logo | QDID 150839 (Bluetooth 4.2)
QDID 193238 (Bluetooth 5)
|
|---|
|
