Category: Panel Computing
TEP-0500-IMX7 FRONT

TEP-0500-IMX7

  • The TEP-0500-IMX7 is a low-power consumption HMI based on an NXP i.MX7 Dual core Cortex-A7™ + M4™ processor.
  • Features a 5-inch widescreen ratio multitouch PCAP touch screen with LED backlight and brushed aluminum front bezel.
  • Edge-computing ready with internal mini-PCIe expansion + SIM card slot for cloud connectivity.
  • 2 RS-232, 2 CAN, 8 GPIO, 2 Gigabit Ethernet and USB interfaces.
  • Orderable with single voltage 12V DC, wide voltage 9 - 36V DC or 802.3.at PoE (power over ethernet) options.
TEP-0700-IMX7 FRONT

TEP-0700-IMX7

  • The TEP-0700-IMX7 is a low-power consumption HMI based on an NXP i.MX7 Dual core Cortex-A7™ + M4™ processor.
  • Features a 7-inch widescreen ratio multitouch PCAP touch screen with LED backlight and brushed aluminum front bezel.
  • Edge-computing ready with internal mini-PCIe expansion + SIM card slot for LTE/5G cloud connectivity.
  • 2 RS-232, 2 CAN, 8 GPIO, 2 Gigabit Ethernet and USB interfaces.
  • Orderable with single voltage 12V DC, wide voltage 9 - 36V DC or 802.3.at PoE (power over ethernet) options.
  • Linux, Yocto, Ubuntu, Android runtime images and full source code available.
TC-0700 FRONT

TC-0700

  • TC-0700 is an ultra-slim, low power, fanless HMI based on a Solo or DualLite core ARM Cortex-A9 NXP i.MX6processor.
  • 7 inch Projective Capacitive (multitouch) high resolution (1024 x 600) bright (500 nits) widescreen LCD with LED backlight.
  • Galvanic isolated CAN Bus and Serial (RS-232/422/485) ports.
  • USB 2.0 Host, USB 2.0 OTG, microSD card slot, 4x GPIO (galvanic isolated) and HDMI for secondary display.
  • PoE function 802.3at or 9-36V DC power input.
  • Available with colorful bezels.
TC-0710 FRONT

TC-0710

  • TC-0710 is an ultra-efficient, low power, fanless HMI based on a Solo, DualLite, or Quad core ARM Cortex-A9 NXP i.MX6 processor.
  • 7 inch Projective Capacitive (multitouch) high resolution (1024 x 600) bright (500 nits) widescreen LCD with LED backlight.
  • Galvanic isolated CAN Bus and Serial (RS-232/422/485) ports.
  • USB 2.0 Host, USB 2.0 OTG, microSD card slot, 4x GPIO (galvanic isolated) and HDMI for secondary display.
  • PoE function 802.3at or 10-30V DC power input.
  • Available with brushed aluminum bezel.
TEP-1010-IMX6 FRONT

TEP-1010-IMX6

  • The TEP-1010-IMX6 is a scalable multimedia HMI based on an NXP i.MX6 Solo, DualLite, or Quad multicore Cortex-A9™ processor supporting 2D/3D graphic applications.
  • Features a 10.1-inch widescreen ratio multitouch PCAP touch screen with LED backlight and brushed aluminum front bezel.
  • Edge-computing ready with internal mini-PCIe expansion + SIM Card slot for LTE/5G cloud connectivity.
  • Orderable with single voltage 12V DC, wide voltage 9 - 36V DC or 802.3.at PoE (power over ethernet) options and GPIO, UART, CAN interfaces (optional galvanic isolated).
  • HDMI and VGA secondary display support.
  • Linux, Yocto, Ubuntu, Android runtime images and full source code available.
TEP-1560-IMX6 FRONT

TEP-1560-IMX6

  • The TEP-1560-IMX6 is A scalable multimedia HMI based on an NXP i.MX6 Solo, DualLite, or Quad multicore Cortex-A9™ processor supporting 2D/3D graphic applications.
  • Features a 15.6-inch widescreen ratio multitouch PCAP touch screen with LED backlight and brushed aluminum front bezel.
  • Edge-computing ready with internal mini-PCIe expansion + SIM Card slot for LTE/5G cloud connectivity.
  • Orderable with single voltage 12V DC, wide voltage 9 - 36V DC or 802.3.at PoE (power over ethernet) options and GPIO, UART, CAN interfaces (optional galvanic isolated).
  • HDMI and VGA secondary display support.
  • Linux, Yocto, Ubuntu, Android runtime images and full source code available.
