UVCI-AR1335-SL Front side

UVCI-AR1335-SL Ftont

UVCI-AR1335-SL Back

UVCI-AR1335-C-S85-IR

SKU: UVCIAR1335CS85IR Category: USB3 Type-C Cameras

More Information

Product Brief

USB3 Type-C PCB Board Camera with onsemi AR1335 13MP Color Rolling Shutter with Onboard ISP + 85 Degree M12 Lens with IR-Cut Filter

Available on backorder

Quantity	Discount (%)	Price
1 - 99	—	$130.00
100 - 249	5.77 %	$122.50
250 - 499	10 %	$117.00
500+	13.08 %	$113.00

x

Additional information

Camera Information

CMOS Sensor	onsemi AR1335
Active Pixels	4208 (H) x 3120 (V) = 13MP
Pixel Size	1.1 μm x 1.1 μm
Optical Format	1/3.2” (Diagonal 5.8 mm)
Shutter Type	Rolling Shutter
Chromaticity	Color
Illuminated type	Back Side Illuminated (BSI)
Maximum Frame Rate (MJPEG)	4200 x 3120 @ 20 fps 3840 x 2160 @ 30 fps 2560 x 1440 @ 30 fps 1920 x 1080 @ 60 fps 1280 x 720 @ 60 fps 640 x 480 @ 120 fps
Maximum Frame Rate (UYVY)	4200 x 3120 @ 5 fps 3840 x 2160 @ 7 fps 2560 x 1440 @ 30 fps 1920 x 1080 @ 30 fps 1280 x 720 @ 30 fps 640 x 480 @ 30 fps
Maximum S/N Ratio	37 dB
HDR Support	Yes
Output Format	UYVY MJPEG (JPG)

Interface

Connector	USB Type-C 5 Gbps

Power Specifications

Supply Voltage	5V ± 5%
Power Consumption	UYVY 4200 x 3120 @ 12 fps ≤ 1.4W
Standby Power	≤ 0.3W Standby

Software Support

Operation Systems	UVC Plug-and-play Windows 10/11 Linux Yocto
SDK	VizionViewer™ SDK

Lens Information

Aperture	F2.4
BFL	3.4 mm
Distortion	< 3.9%
Focal Length	3.2 mm
Focus Type	Fixed Focus
IR-Filter	650 nm
Lens D-FOV	91.0°
Lens H-FOV	82.0°
Lens Operating Temperature	-20°C to +60°C
Lens V-FOV	51.4°
MOD	0.3 m
Module D-FOV	84.6° ± 5%
Module H-FOV	70.3° ± 5%
Module V-FOV	55.2° ± 5%
TTL	22 mm

Environmental and Mechanical

Dimensions	24.5(W) x 24.5(H) x 25.6(D) mm
Relative Humidity	10 to 90 %
MTBF	50,000 Hours
Shock	15G half-sine 11 ms duration
Operation Temperature	-30°C to +70℃
Vibration	1 Grms random 5-500Hz hr/axis
Weight	18 grams

Certification and Compliance

Certification	Compliant with CE / FCC / RoHS / REACH directives

Commercial Information

Brand	TechNexion
Country of Origin	Taiwan
HTSN	8525.80.5050
ECCN	EAR99
REACH / RoHS	Yes

UVCI-AR1335 Block Diagram

UVCI-AR1335 Dimension

AR1335 Spectral Characteristics
