Specifications
Additional information
Brand | TechNexion |
---|---|
Country of Origin | Taiwan |
ECCN | 5A992.c Mass Market |
CCATS | 740.17(b)(1) Mass Market (No License Required) |
REACH / RoHS | Yes |
HTSN | 8473.30.1180 |
Processor | NXP i.MX6 Quad |
Processor Speed | 1.0 Ghz |
Architecture | ARM Cortex-A9 |
PMIC | Discrete Power Solution |
Memory | 1GB DDR3 |
Storage | MicroSD |
Board-to-Board Connector | PICO 70-pin Hirose connectors |
System on Module | PICO SOM |
Network LAN | RGMII |
Wi-Fi | Broadcom BCM4339 802.11 a/b/g/n/ac |
Bluetooth | Broadcom BCM4339 BT 4.1 (BR+EDR+BLE) |
Antenna | u.FL connector |
I/O | RGMII, HDMI, LVDS, RGB TTL, MIPI CSI-2, MIPI DSI, PCIe, SATA, USB, USB OTG, I²S, SDIO, CAN, UART, SPI, I²C, PWM, GPIO |
Camera | MIPI CSI (4 lanes) |
Audio Codec | On carrier board |
Power Input | 4.2-5.25V DC |
Power Consumption | Depending on Configuration |
Extended Support | Commercial Linux |
Standard Support | Linux, Yocto, Ubuntu, Android |
Certification | Compliant with CE / FCC / RoHS / REACH directives |
Bluetooth Logo | QDID 63292 (Bluetooth 4.1) |
Dimensions | 37 x 40 mm |
Form Factor | PICO |
Relative Humidity | 10 to 90 % |
MTBF | 100,000+ Hours |
Shock | 15G half-sine 11 ms duration |
Operation Temperature | Commercial: 0°C to +60°C |
Vibration | 1 Grms random 5-500Hz hr/axis |
GPU Engine | Vivante GC2000 (Quad), Vivante GC320 (2D Composition), Vivante GC355 (Quad) |
Weight | 8 grams |
Audio Interface | I²S (1 channel) |
Video Decode | 1080p60 H.264 (Quad) |
Video Encode | 1080p30 H.264 |
